Build Specs
- Frame: Toray T800/T1000/M46 High-Modulus Carbon Blend
- Fork: Winspace T1550 Full Carbon, 12mm Thru-Axle
- Headset: 1-1/2" Integrated
- Seatpost: Winspace S23 VCLS Carbon (0/15mm Setback Options)
- Frame Weight: 855g (Size M, painted)
- Groupset Compatibility: Shimano Di2, SRAM eTap/AXS, Campagnolo EPS
- Groupset: Shimano 105 Di2, 2x12 Speed, Electronic
- Shifters: Shimano 105 Di2 ST-R7170
- Crankset: Shimano 105 FC-R7100, 50/34T
- Front Derailleur: Shimano 105 Di2 FD-R7150
- Rear Derailleur: Shimano 105 Di2 RD-R7150
- Cassette: Shimano 105 CS-R7101, 11-34T, 12-Speed
- Chain: KMC X12R
Bottom Bracket: Token T47 85.5mm - Brakes: Shimano 105 Hydraulic Disc
Brake Rotors: Shimano RT64, 160mm Front / 140mm Re
- Handlebar: Zero SL Integrated Handlebar
- Saddle: Selle Italia Novus Boost Evo Superflow L3
- Bar Tape: Selle Italia SG-Tape
- Wheelset: Lún HYPER 3 D45 Carbon
- Tires: Continental Ultra Sport III, 700x28c
- Total Weight: Approx. 7.4 kg
What's in the Box
- Saddle
- Seatpost
- Seatpost Wedge
- Carbon Rail Saddle Clamp
- Computer Mount Kit
- Spare Derailleur Hanger (one is pre-installed)
- Seatpost Dust Cover
- Water Bottle Cage Bolts (x4)
- Assembly Tool Kit
- Pedals
Geometry Chart
